GN 240Snelkoppelingen

Snelkoppelingen

met radiale offset-compensatie

  • Icons/__logo__RoHS__.png
Snelkoppelingen
Snelkoppelingen

GN 240

Reset
Code
d
l5 +1.0
x
e1
e2 ≈
l1 ≈
l2
l3 min.
l4
A/F 1
A/F 2
x max radial off-set
GN 240-M6-A
M6
9
0.6
21
-
37.5
18
11
14
19
10
0.6
GN 240-M8-A
M8
11.5
0.7
26
-
45
22.5
13.5
17
24
13
0.7
GN 240-M10-A
M10
16
0.7
30
-
56
29
16
20
27
17
0.7
GN 240-M10x1,25-A
M10x1.25
16
0.7
30
-
56
29
16
20
27
17
0.7
GN 240-M12-A
M12
17
0.8
32.5
-
66.5
34
21
25
30
19
0.8
GN 240-M12x1,25-A
M12x1.25
17
0.8
32.5
-
66.5
34
21
25
30
19
0.8
GN 240-M16-A
M16
23
1
39
-
83
42
25
30
36
24
1
GN 240-M16x1,5-A
M16x1.5
23
1
39
-
83
42
25
30
36
24
1
GN 240-M20-A
M20
23.5
1
44
-
93.5
45.5
29
35
41
30
1
GN 240-M20x1,5-A
M20x1.5
23.5
1
44
-
93.5
45.5
29
35
41
30
1
GN 240-M6-B
M6
9
0.6
21
11
37.5
18
11
-
19
10
0.6
GN 240-M8-B
M8
11.5
0.7
26
14.5
45
22.5
13.5
-
24
13
0.7
GN 240-M10-B
M10
16
0.7
30
19
56
29
16
-
27
17
0.7
GN 240-M10x1,25-B
M10x1.25
16
0.7
30
19
56
29
16
-
27
17
0.7
GN 240-M12-B
M12
17
0.8
32.5
21
66.5
34
21
-
30
19
0.8
GN 240-M12x1,25-B
M12x1.25
17
0.8
32.5
21
66.5
34
21
-
30
19
0.8
GN 240-M16-B
M16
23
1
39
27
83
42
25
-
36
24
1
GN 240-M16x1,5-B
M16x1.5
23
1
39
27
83
42
25
-
36
24
1
GN 240-M20-B
M20
23.5
1
44
34
93.5
45.5
29
-
41
30
1
GN 240-M20x1,5-B
M20x1.5
23.5
1
44
34
93.5
45.5
29
-
41
30
1

Types

  • Type A: with male thread
  • Type B: with female thread

Steel

  • tempered
  • phosphated

Quick-fit couplings GN 240 have been designed for the purpose of compensating a radial shaft off-set (x). A typical application is the axial link to a piston rod of a cylinder operating in any type of fixture or system.

The coupling is not designed for the transfer of torque.
