Rod end M6
Aansluiting M6
|
Code
|
Omschrijving
|
Connection
|
for Ø pin
|
E
|
Material
|
|
|---|---|---|---|---|---|---|
|
ST092259 (ZD - M6 - Ø8,5 - E=16,5mm)
|
M6
|
8
|
16.5
|
Zamac
| ||
|
ST092263 (ALU - M6 - Ø8,6 - E=17,5mm)
|
M6
|
8
|
17.5
|
Aluminium
| ||
|
ST1304 ( ST - M6 - Ø8,1 - E=22mm)
|
M6
|
8
|
22
|
Zinc plated steel
| ||
|
ST1305 ( ST - M6 - Ø6,1 - E=25mm)
|
M6
|
6
|
25
|
Zinc plated steel
| ||
|
ST1305-8 ( ST - M6 - Ø8,1 - E=25mm)
|
M6
|
8
|
25
|
Zinc plated steel
| ||
|
ST4180 ( ST - M6 - Ø10,1 - E=20mm)
|
M6
|
10
|
20
|
Zinc plated steel
| ||
|
HGCHM6 (ST - M6 - Ø8,1 - E=20mm)
|
M6
|
6
|
20
|
Zinc plated steel
|
