GN-736.1Bedieningshandwielen

Met standaardschaal

Aluminium met schaalnok / standaard schaal

Technical datasheet

GN-736.1

Reset

Code	d₁	d₂ H8 Bore	d₃	d₄	d₅	b -0.5	h	l₁	l₂	l₃ ≈	r	ø Cylindrical knob

GN 736.1-52-Z10-D-S	52	10	50	37	39.5	13	3.8	23	17	19	15.5	13
GN 736.1-62-Z10-D-S	62	10	60	47	49.5	13	3.8	23	17	21	20.5	14

Types

Type A: Without handle
Type D: With revolving knob

Bore codes

Version B: Without keyway
Version K: With keyway DIN 6885-1 P9
Version Z: With collet

Coding

Coding S: With standard scale 0...90, 100 graduations acc. scale scheme d₁/100 A RA 0-10 20...90/10 (only for bore code Z with collet)

Wheel body

Aluminum

Anodized, black

Scale for coding S

Engraved

Cover

Plastic, light gray

Collet / Hex nut

Brass

Grub screw DIN 916

Stainless steel

with internal hex and serrated point

Revolving cylindrical knob

Plastic, Polyamide (PA)

Black, matte

Spindle

Stainless steel AISI 303

Control handwheels GN 736.1 are used for setting operations with low torque. Coarse setting is made by means of the cylindrical handle (fingertip grip) followed by fine setting using the knurled rim of the knob.

The model fitted with collet offers an absolutely reliable mounting on the shaft and at the same time allows an easy setting of the adjustable scale ring wheel. The scale is wear resistant and easily legible since the engraved alu coloured numbers contrast with the black anodized surface. Besides the standard scale (Coding S) the control handwheels can be supplied with any type of graduation.

Full details of the available graduations, numbering sequence, number position and type of scale see under 'How to Order Graduations' .
