GN 114.2Borgpennen

Borgpennen

Staal, met axiale vergrendeling (pal)

  • Icons/__logo__RoHS__.png
pdf Other documents
Borgpennen
Borgpennen

GN 114.2

Reset
Code
d1 -0.1
l1 +0.4
a
b
d2
d3
d4
d5
l2
l3
Load in kN ≈
Load capacity in kN ≈
Double sided
shearing resistance
according DIN 50141
(breaking strength)
GN 114.2-6-10
6
10
2.3
0.5
7.3 +0.5
5.9
15
30
7
21
14
12
GN 114.2-6-12
6
12
2.3
0.5
7.3 +0.5
5.9
15
30
7
21
14
12
GN 114.2-6-16
6
16
2.3
0.5
7.3 +0.5
5.9
15
30
7
21
14
13
GN 114.2-6-20
6
20
2.3
0.5
7.3 +0.5
5.9
15
30
7
21
14
14
GN 114.2-6-25
6
25
2.3
0.5
7.3 +0.5
5.9
15
30
7
21
14
14
GN 114.2-6-30
6
30
2.3
0.5
7.3 +0.5
5.9
15
30
7
21
14
15
GN 114.2-6-35
6
35
2.3
0.5
7.3 +0.5
5.9
15
30
7
21
14
16
GN 114.2-6-40
6
40
2.3
0.5
7.3 +0.5
5.9
15
30
7
21
14
17
GN 114.2-6-45
6
45
2.3
0.5
7.3 +0.5
5.9
15
30
7
21
14
18
GN 114.2-6-50
6
50
2.3
0.5
7.3 +0.5
5.9
15
30
7
21
14
18
GN 114.2-6-60
6
60
2.3
0.5
7.3 +0.5
5.9
15
30
7
21
14
23
GN 114.2-6-70
6
70
2.3
0.5
7.3 +0.5
5.9
15
30
7
21
14
23
GN 114.2-6-80
6
80
2.3
0.5
7.3 +0.5
5.9
15
30
7
21
14
27
GN 114.2-8-10
8
10
2.8
0.6
9.8 +0.5
7.9
15
30
8.4
21
28
26
GN 114.2-8-16
8
16
2.8
0.6
9.8 +0.5
7.9
15
30
8.4
21
28
16
GN 114.2-8-20
8
20
2.8
0.6
9.8 +0.5
7.9
15
30
8.4
21
28
25
GN 114.2-8-25
8
25
2.8
0.6
9.8 +0.5
7.9
15
30
8.4
21
28
27
GN 114.2-8-30
8
30
2.8
0.6
9.8 +0.5
7.9
15
30
8.4
21
28
29
GN 114.2-8-35
8
35
2.8
0.6
9.8 +0.5
7.9
15
30
8.4
21
28
29
GN 114.2-8-40
8
40
2.8
0.6
9.8 +0.5
7.9
15
30
8.4
21
28
32
GN 114.2-8-45
8
45
2.8
0.6
9.8 +0.5
7.9
15
30
8.4
21
28
34
GN 114.2-8-50
8
50
2.8
0.6
9.8 +0.5
7.9
15
30
8.4
21
28
35
GN 114.2-8-60
8
60
2.8
0.6
9.8 +0.5
7.9
15
30
8.4
21
28
41
GN 114.2-8-70
8
70
2.8
0.6
9.8 +0.5
7.9
15
30
8.4
21
28
47
GN 114.2-8-80
8
80
2.8
0.6
9.8 +0.5
7.9
15
30
8.4
21
28
50
GN 114.2-8-90
8
90
2.8
0.6
9.8 +0.5
7.9
15
30
8.4
21
28
52
GN 114.2-8-100
8
100
2.8
0.6
9.8 +0.5
7.9
15
30
8.4
21
28
54
GN 114.2-10-15
10
15
3.3
1
11.7 +1
9.9
18
34
9.8
26
38
24
GN 114.2-10-20
10
20
3.3
1
11.7 +1
9.9
18
34
9.8
26
38
26
GN 114.2-10-25
10
25
3.3
1
11.7 +1
9.9
18
34
9.8
26
38
28
GN 114.2-10-30
10
30
3.3
1
11.7 +1
9.9
18
34
9.8
26
38
31
GN 114.2-10-35
10
35
3.3
1
11.7 +1
9.9
18
34
9.8
26
38
33
GN 114.2-10-40
10
40
3.3
1
11.7 +1
9.9
18
34
9.8
26
38
35
GN 114.2-10-45
10
45
3.3
1
11.7 +1
9.9
18
34
9.8
26
38
37
GN 114.2-10-50
10
50
3.3
1
11.7 +1
9.9
18
34
9.8
26
38
39
GN 114.2-10-60
10
60
3.3
1
11.7 +1
9.9
18
34
9.8
26
38
44
GN 114.2-10-70
10
70
3.3
1
11.7 +1
9.9
18
34
9.8
26
38
49
GN 114.2-10-80
10
80
3.3
1
11.7 +1
9.9
18
34
9.8
26
38
54
GN 114.2-10-90
10
90
3.3
1
11.7 +1
9.9
18
34
9.8
26
38
60
GN 114.2-10-100
10
100
3.3
1
11.7 +1
9.9
18
34
9.8
26
38
63
GN 114.2-10-110
10
110
3.3
1
11.7 +1
9.9
18
34
9.8
26
38
67
GN 114.2-10-120
10
120
3.3
1
11.7 +1
9.9
18
34
9.8
26
38
73
GN 114.2-12-20
12
20
3.8
1
13.7 +1
11.9
18
34
11.3
26
61
33
GN 114.2-12-25
12
25
3.8
1
13.7 +1
11.9
18
34
11.3
26
61
37
GN 114.2-12-30
12
30
3.8
1
13.7 +1
11.9
18
34
11.3
26
61
41
GN 114.2-12-35
12
35
3.8
1
13.7 +1
11.9
18
34
11.3
26
61
44
GN 114.2-12-40
12
40
3.8
1
13.7 +1
11.9
18
34
11.3
26
61
48
GN 114.2-12-45
12
45
3.8
1
13.7 +1
11.9
18
34
11.3
26
61
51
GN 114.2-12-50
12
50
3.8
1
13.7 +1
11.9
18
34
11.3
26
61
55
GN 114.2-12-60
12
60
3.8
1
13.7 +1
11.9
18
34
11.3
26
61
62
GN 114.2-12-70
12
70
3.8
1
13.7 +1
11.9
18
34
11.3
26
61
69
GN 114.2-12-80
12
80
3.8
1
13.7 +1
11.9
18
34
11.3
26
61
76
GN 114.2-12-90
12
90
3.8
1
13.7 +1
11.9
18
34
11.3
26
61
90
GN 114.2-12-100
12
100
3.8
1
13.7 +1
11.9
18
34
11.3
26
61
95
GN 114.2-12-110
12
110
3.8
1
13.7 +1
11.9
18
34
11.3
26
61
102
GN 114.2-12-120
12
120
3.8
1
13.7 +1
11.9
18
34
11.3
26
61
112
GN 114.2-16-30
16
30
4.8
1.2
18.7 +1
15.9
22
40
14.2
32
113
78
GN 114.2-16-35
16
35
4.8
1.2
18.7 +1
15.9
22
40
14.2
32
113
85
GN 114.2-16-40
16
40
4.8
1.2
18.7 +1
15.9
22
40
14.2
32
113
92
GN 114.2-16-45
16
45
4.8
1.2
18.7 +1
15.9
22
40
14.2
32
113
85
GN 114.2-16-50
16
50
4.8
1.2
18.7 +1
15.9
22
40
14.2
32
113
105
GN 114.2-16-60
16
60
4.8
1.2
18.7 +1
15.9
22
40
14.2
32
113
118
GN 114.2-16-70
16
70
4.8
1.2
18.7 +1
15.9
22
40
14.2
32
113
133
GN 114.2-16-80
16
80
4.8
1.2
18.7 +1
15.9
22
40
14.2
32
113
144
GN 114.2-16-90
16
90
4.8
1.2
18.7 +1
15.9
22
40
14.2
32
113
147
GN 114.2-16-100
16
100
4.8
1.2
18.7 +1
15.9
22
40
14.2
32
113
173
GN 114.2-16-110
16
110
4.8
1.2
18.7 +1
15.9
22
40
14.2
32
113
186
GN 114.2-16-120
16
120
4.8
1.2
18.7 +1
15.9
22
40
14.2
32
113
199
GN 114.2-16-130
16
130
4.8
1.2
18.7 +1
15.9
22
40
14.2
32
113
213
GN 114.2-16-140
16
140
4.8
1.2
18.7 +1
15.9
22
40
14.2
32
113
226
GN 114.2-16-150
16
150
4.8
1.2
18.7 +1
15.9
22
40
14.2
32
113
239
GN 114.2-20-30
20
30
4.8
1.2
22.7 +1
19.8
25
40
14.8
33
187
125
GN 114.2-20-35
20
35
4.8
1.2
22.7 +1
19.8
25
40
14.8
33
187
136
GN 114.2-20-40
20
40
4.8
1.2
22.7 +1
19.8
25
40
14.8
33
187
147
GN 114.2-20-45
20
45
4.8
1.2
22.7 +1
19.8
25
40
14.8
33
187
158
GN 114.2-20-50
20
50
4.8
1.2
22.7 +1
19.8
25
40
14.8
33
187
169
GN 114.2-20-60
20
60
4.8
1.2
22.7 +1
19.8
25
40
14.8
33
187
191
GN 114.2-20-70
20
70
4.8
1.2
22.7 +1
19.8
25
40
14.8
33
187
214
GN 114.2-20-80
20
80
4.8
1.2
22.7 +1
19.8
25
40
14.8
33
187
234
GN 114.2-20-90
20
90
4.8
1.2
22.7 +1
19.8
25
40
14.8
33
187
258
GN 114.2-20-100
20
100
4.8
1.2
22.7 +1
19.8
25
40
14.8
33
187
277
GN 114.2-20-110
20
110
4.8
1.2
22.7 +1
19.8
25
40
14.8
33
187
302
GN 114.2-20-120
20
120
4.8
1.2
22.7 +1
19.8
25
40
14.8
33
187
326
GN 114.2-20-130
20
130
4.8
1.2
22.7 +1
19.8
25
40
14.8
33
187
350
GN 114.2-20-140
20
140
4.8
1.2
22.7 +1
19.8
25
40
14.8
33
187
368
GN 114.2-20-150
20
150
4.8
1.2
22.7 +1
19.8
25
40
14.8
33
187
395

Pin

Steel

Zinc plated, blue passivated

Pawl

Stainless Steel AISI 304 (sheet metal)

Knob

Plastic (Polyamide PA)

  • Black-gray
  • Temperature resistant up to 80 °C

Push button / Slide

Plastic

  • Push button: red
  • Temperature resistant up to 80 °C

Pressure spring

Stainless steel AISI 301

Locking pins with axial lock GN 114.2 are used for quick fixing, connecting and locking of various jig and fixture systems. A typical application is location pins which have to be often removed and re-placed again.

The rectangular pawls made of Stainless Steel sheet metal keep the locking pin in an axial position in the bore. It can be retracted by pressing the button, once released it returns the pressure spring into its locking position.

The technical appendix contains the load capacities for the double-sided shearing resistance (breaking strength).
