GN 826-HÉléments de serrage

Vis de serrage avec poignée réglable

pour broches réglables

Technical datasheet

GN 826-H

Vis de serrage avec poignée réglable

GN 826-S

Vis de serrage avec hexagone interne

GN 826-H

Réinitialiser

Code	d₁	d₂ H9	d₃	b	m	l₁	l₂ max.	l₃ max.

GN 826-40-B8-H-ELS	40	B 8	4.3	16	28	30	50	27	80
GN 826-40-B10-H-ELS	40	B 10	4.3	16	28	30	50	27	79
GN 826-50-B8-H-ELS	50	B 8	5.3	16	36	30	56	32	110
GN 826-50-B10-H-ELS	50	B 10	5.3	16	36	30	56	32	110
GN 826-50-B12-H-ELS	50	B 12	5.3	16	36	30	56	32	109
GN 826-60-B10-H-ELS	60	B 10	5.3	16	44	30	61	36	148
GN 826-60-B12-H-ELS	60	B 12	5.3	16	44	30	61	36	148

Types

Type H: Clamping screw with adjustable handle
Type S: Clamping screw with internal hex

Clamping Element

Aluminum

Anodized, black ELS

Wedge

Brass

Adjustable hand lever for type H

Zinc die casting

Powder coated

Black, RAL 9005, textured finish

With setting screw

Stainless steel AISI 303

Clamping screw for type S

Stainless steel AISI 303

Clamping elements GN 826 are normally used in connection with control knobs and smaller handwheels.

Spindles can so be clamped gently and easily and without much construction and installation effort. The clamping wedge stiffens the spindle, e.g., to prevent maladjustments caused by vibrations or to secure the spindle after adjustment.

This clamping element can also be used to store the spindle.

The clamping element may be mounted such that the clamping lever / the clamping screw is positioned either on the left or the right hand side.

Indicator arrows which can be attached to the circumference of the clamping element are found under GN 711.1.
