7062.3-65-B40-NI
GN 7062.3 Colliers d'arbre semi-fendus
Délai: 1-2 semaines Toutes les tailles et variantes de GN 7062.3
🔒 Prix, stock en temps réel & téléchargements CAO
Connectez-vous pour voir vos prix et le stock, télécharger les fichiers CAO et commander directement en ligne.
Se connecter Demander un compte
Fiche technique
Caractéristiques techniques
- Code
- GN 7062.3-65-B40-NI
- d1
- 65
- d2 H10
- B 40
- b1
- 15
- b2
- 18
- d3
- M 6
- s
- 4
- x ≈ Max. protrusion
of cap screw - 0.5
- Adjustable hand lever for d3
- GN 311-45-M6-20-SW
- 196
Stainless steel AISI 316LHC NI
Sintered
Damping washer
Elastomer (PUR)
- 70 Shore A
- Temperature resistant up to 80 °C
- Transparent
Socket cap screw DIN 912
Stainless steel AISI 304
The affixed damping washer of the semi-split shaft collars GN 7062.3 absorbs mild shocks and has a sound-damping effect when the shaft collars come into contact with other components.
They can be assembled safely and easily with a high clamping force by reducing the slot height, without damaging the surface of shafts and axles.
The thread d3 for sizes d1 = 30 to 36 is designed as a through hole; for sizes d1 = 42 and larger, it is designed as blind hole.
- Adjustable Hand Levers GN 311
