Technical datasheet
GN 53.2Aimants
Aimants
Forme rectangulaire , avec boîtier en plastique
GN 53.2
|
Code
|
l
|
b
|
h
|
Nominal magnetic force
in N |
|
|---|---|---|---|---|---|
|
GN 53.2-ND-55-RT
|
55
|
22.5
|
8.5
|
48
|
25
|
Housing
Plastic
- White, RAL 9003 WS
- Gray, RAL 7040 GR
- Black, RAL 9004 SW
- Red, RAL 3031 RT
Magnet material
NdFeB ND
Neodymium, iron, boron
Temperature resistant up to 80 °C
Magnets GN 53.2 work in combination with the flat, rectangular plastic housing as a system for holding documents, templates, drawings etc. that are used in technical environments.
The neodymium magnets used are characterized by a high retaining force.
- Other colors
- Magnet material hard ferrite
- With custom imprint
